Description
Sealey MIG/TIG & MMA (ARC/STICK) Inverter Welder 120A 230V
IGBT INVERTER TECHNOLOGY – IGBT Inverter fan-cooled DC power supply for MIG/TIG and MMA/ARC welding applications up to 120A.
3 IN 1 FUNCTION – Multi-functional welder bringing together MIG/TIG and MMA application all into one compact unit ideal for workshops, garages, bodyshops and mobile technicians.
HIGHLY PORTABLE – Ultra-compact and lightweight weighing just 6.9kg and supplied with handy carry strap making this unit highly portable allowing the welder to be taken to the job at hand.
FEATURING – Hot start, anti-stick, forced air cooling and thermal cut out protection.
WELDING CAPABILITY – Unit can MIG weld using 1kg Ø0.8/0.9/1mm solid wire and Ø0.8/Ø0.9mm flux cored MIG wire, MMA/ARC weld Ø1.6 up to Ø3.2mm electrode.
SUPPLIED WITH – Supplied with fixed non-live MIG torch, 1.4m earth cable/clamp, 1.6m electrode holder.
DUTY CYCLE – MIG – 60% @ 120A, TIG – 60% @ 120A, MMA/ARC – 60% @ 120A.
Specification:
- Model No MINIMIG120i
- Brand: Sealey
- Nett Weight: 6.9kg
- Welding Current: 10-120A
- Duty Cycle MIG: 60% @ 120A, 100% @ 76A
- Duty Cycle MMA/ARC: 60% @ 120A, 100% @ 76A
- Duty Cycle TIG: 60% @ 120A, 100% @ 76A
- Wire Capacity: 1kg Ø0.8/0.9/1.0mm solid wire and Ø0.8/Ø0.9mm flux cored MIG wire,
- Electrode Capacity: 1.6-3.2mm
- Absorbed Power: 4.4kW
- Supply: 230V 16A*
- Insualtion Class: H
- IP Rating: IP21S
- Note* To achieve maximum power a 16A supply may be required.
Product Guarantee: 1 Year
Catalogue Page: Page 995
Downloadable Files:
- Instructions: View Here
- Parts Diagram: View Here
