Description
Sealey ATV/Quad Recovery Winch 2040kg (4500lb) Line Pull 12V
Suitable for ATV and quad bike mounting, these high-speed winches offer a combination of performance with durability.
High power 2.5kW (3.25hp) 12V DC permanent magnet type motor gives first class pulling power.
All-metal chassis for long-life and low maintenance.
Motor can easily be rotated 90° to meet various wiring and mounting requirements.
Patented unique automatic spring brake, reliable in full load operation.
High quality wire rope feeds through 4-way roller fairlead for even distribution of cable onto drum.
Cable Length: 17m.
Line Pull*: 2040kg(4500lb).
IP67 rated.
Gear Ratio: 180:1.*Performance quoted at first layer of cable on drum.
Specification:
- Model No ATV2040
- Brand: Sealey
- Consumable Parts: ATV2040.WR – Wire Rope (Ø5.4mm x 17m) for ATV2040, ATV2040.DR – Dyneema Rope (Ø5.5mm x 17m) for ATV2040
- Current Draw: No-Load – 30A, Maximum Load – 185A
- Gear Ratio: 180:1
- Line Pull*: 2040kg(4500lb)
- Line Speed*: No Load – 4.5m/min, Maximum Load – 1.3m/min
- Motor Power: 2.5kW(3.25hp)
- Nett Weight: 13.9kg
- Note: *Performance quoted at first layer of cable on drum
- Rated Capacity: Layer 1: 2043kg, Layer 4: 1234kg
- Supply: 12V
- Wire Rope Diameter: 5.4mm
- Wire Rope Length: 17m
Product Guarantee: 1 Year
Catalogue Page: Page 1458
Downloadable Files:
- Instructions: View Here
- Parts Diagram: View Here
