Sealey 160A 230V Inverter Welder

Description

Ultra-compact and lightweight unit weighing just 4kg approx.

Portability allows the welder to be taken to the job at hand, ideal for mobile technicians.

Unit can ARC/MMA weld a variety of rods including rutile, basic and stainless from Ø1.6mm up to Ø4mm.

Features LED display, with thermal cut-out protection, anti-stick, arc force and hot start functions.

Supplied with 1.6m 16mm² cable with electrode holder and a 1.4m 16mm² earth clamp and cable, both with 10-25 dinse connectors.

Forced air cooling system.
Specification:

• Model No MINIMW160i
• Brand: Sealey
• Nett Weight: 4.1Kg
• Welding Current: 20-160A
• Duty Cycle: 100% @ 124A, 60% @160A
• Electrode Capacity: Ø1.6-4mm
• Absorbed Power: 5kW

({IF[“Supply: 230V-16A**Note: To achieve maximum power a 16A supply may be required.”!=””]})

• Supply: 230V-16A**Note: To achieve maximum power a 16A supply may be required.

({ENDIF})

• Protection: IP21S
• Weight: 4.1Kg

Product Guarantee: 1 Year
Catalogue Page: Page 994
Downloadable Files:

• Instructions: View Here
• Parts Diagram: View Here
