Sealey Air Compressor 24L V-Twin Direct Drive 2.5hp Cabinet Low Noise
Air Displacement: 10.3cfm(292L/min).
Maximum Free Air Delivery: 7.5cfm(212L/min).
Maximum Pressure: 145psi(10bar).
Cast iron cylinder head, compact size and quiet running features make this compressor unit suitable for installation near or in working area.
Noise output is just 57dB(A) (at 1m).
Includes heavy-duty single phase electric motor with soft start circuitry to enable smooth operation from 13Amp supply.
Integral 24 litre tank may be supplemented by additional receiver (see Model No. SA200T).
Regulated pressure output with gauges on control panel for precise adjustment.
Fitted with 3-pin plug.
This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Specification:
- Model No SAC82425VLN
- Air Displacement cfm(L/min): 10.3(292)
- Brand: Sealey
- Maximum Free Air Delivery cfm(L/min): 7.5(212)
- Maximum Pressure: 145psi(10bar)
- Minimum Rated Supply: 13A
- Motor Output: 2.5hp
- Nett Weight: 96kg
- Noise Level: 57dB(A)
- Oil Capacity: 0.43L
- Outlet: 1/4″BSP Female Thread
- Phase: 1ph
- Receiver Capacity: 24L
- Size (W x D x H): 490 x 700 x 930mm
- Supply: 230V/13A
Product Guarantee: 1 Year
Catalogue Page: Page 782
Downloadable Files:
- Instructions: View Here
- Material Safety Data Sheet: View Here
- Parts Diagram: View Here
