Description
Sealey Premier Air/Hydraulic Floor Type Press with Foot Pedal 30 Tonne
Heavy-duty steel frame construction with side mounted air motor powering hydraulic pump unit.
2-Speed manual operation.
Sliding hydraulic ram assembly giving 200mm of lateral travel for off-centre pressing applications.
Fitted with ram pressure gauge.
Supplied with flat pressing plate/V-blocks.
5 Year guarantee*.
This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Specification:
- Model No YK309FAH
- Air Consumption: 9cfm
- Bench or Floor Mounting: Floor
- Brand: Sealey Premier
- Capacity: 30 Tonne
- Gauge Included: Yes
- Lateral Ram Travel: 200mm
- Maximum Height – Ram to Table: 1030mm
- Minimum Height – Ram to Table: 150mm
- Nett Weight: 168kg
- Operating Table Width: 535mm
- Optional Accessories: YKSG30 – Safety Guard, YKPP8 – Press Pin Set
- Overall Height: 1801mm
- Ram Diameter: Ø70mm
- Ram Stroke: 150mm
- Table Aperture: 164mm
- Type: Air/Hydraulic
- Working Table Depth: 184mm
- Working Table Width: 695mm
- Working Table Width: 535mm
Product Guarantee: 5 Years
Catalogue Page: Page 898
Downloadable Files:
- Instructions: View Here
- Material Safety Data Sheet: View Here
- Parts Diagram: View Here
