Description
Sealey Premier Air/Hydraulic Floor Type Press with Foot Pedal 50 Tonne
Heavy-duty steel frame construction with side mounted air motor powering hydraulic pump unit.
2-Speed manual operation.
Sliding hydraulic ram assembly giving 245mm of lateral travel for off-centre pressing applications.
Fitted with ram pressure gauge.
Supplied with table winch and flat pressing plate/V-blocks.
This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
IMPORTANT – A forklift must be available at the delivery point to unload this item.
5 Year guarantee*.
Specification:
- Model No YK509FAH
- Air Consumption: 7cfm
- Bench or Floor Mounting: Floor
- Brand: Sealey Premier
- Capacity: 50 Tonne
- Gauge Included: Yes
- Lateral Ram Travel: 245mm
- Maximum Height – Ram to Table: 1047mm
- Minimum Height – Ram to Table: 67mm
- Nett Weight: 302.5kg
- Operating Table Width: 730mm
- Optional Accessories: YKSG50 – Safety Guard, YKPP8 – Press Pin Set
- Overall Height: 1877mm
- Ram Diameter: Ø75mm
- Ram Stroke: 200mm
- Table Aperture: 235mm
- Type: Air/Hydraulic
- Warranty Information: This is test warranty information.
- Working Table Depth: 259mm
- Working Table Width: 910mm
- Working Table Width: 910mm
Product Guarantee: 5 Years
Catalogue Page: Page 899
Downloadable Files:
- Instructions: View Here
- Material Safety Data Sheet: View Here
- Parts Diagram: View Here
